CAD CAM Training Institute

CNC VMC Operating Training

This course is designed to help students learn machining using SOLIDCAM, a CAM software integrated with SOLIDWORKS which provides a complete set of tools required for part machining. This course is designed for both students and professionals covering all major tools and operation of this software. After completing this course, the trainees/students will be able to control and simulate the Toolpath, and will be able to generate the NC code file.

CAD CAM Training Course Details

1. USER INTERFACE & BASIC OF SOLIDCAM

Overview of SolidCAM
Advantages of SolidCAM
CAM Terminology
Solidworks CAD Features
SolidCAM Manager
Part Stocks
Tool Selection
Feed Rate
Generating and verifying Tool Path
Simulation and G Code Generation

2. SOLIDCAM Mill 2.5D

Face Milling

Machining of faces by contour
Machining of faces by hatch
Machining of faces by spiral
Machining of faces by one pass technology

Profile Milling
Pocket Milling

Machining using contour
Machining using Hatch and Plunging Technology

Drilling

Machining using Drilling
Machining using Reaming
Machining using Boring
Machining using tapping
Standard cycles

Thread Milling
Slot Machining
Feed Rate
Generating and verifying Tool Path
Simulation and G Code Generation

3. SOLIDCAM 3D

HSR Roughing

HM Roughing
Contour Roughing
Hatch Roughing
Rest Roughing

HSM Finishing

Constant Z Machining
Hybrid Constant Z
Helical Machining
Horizontal Machining
Linear Machining
Radial Machining
Spiral Machining
Morphed Machining
Offset Cutting
Boundary Machining
Reset Machining
Pencil Machining
Parallel Pencil Milling
3D Corner Offset
Combine Constant Z

High Speed Surfacing

Parallel Cuts
Parallel to Curves
Parallel to Surface
Perpendicular to Curve
Morph between two boundary curves
Morph between two adjacent surfaces

4. TURNING

Facing Operation
Turning Operation
Drilling Operation
Grooving Operation
Cut Off Operation
Threading Operation
Trochoidal Turning

KEY FEATURES:

Instructors are certified professionals
Counselling on course selection
Training on latest software version
One on one attention by Instructors
Adequate lab sessions for practical understanding
Industry specific projects
Lab with latest equipment's
Regular, Weekend and customized trainings
Lab access for unlimited number of hours
Certificate on course completion
Guidance for placement
